M540 repellent with high-voltage surfaces

Martens and rodent repeller with variable sound frequency (12-24 kHz), with 8 high-voltage plates and a warning LED for maximum and immediate effect. High quality German product for use in cars, agricultural machines, tractors. Wiring via vehicle ignition, waterproof unit (IP65).

The marten shocker device produces an acoustic signal with a frequency of 12-24 kHz at intervals of around 22 seconds for each on and off period. Additionally the device has 8 high-voltage plates on two cables which are charged up by a capacitor in the device to around 400 Volts. The high-voltage plates are mounted in the engine compartment such that a marten entering the compartment and touching one of the plates will get a painful, but not lethal, electric shock. In the time taken for the capacitor to charge up again

device is fastened by means of self-tapping screws or binders in the engine compartment on the carriage.

Technical parameters:

• Supply voltage: 12 V DC
• Supply current: 30 mA
• Power consumption: 0.42 W
• Volume: Approx. 85 dB
• Frequency: approximately 12kHz - 24kHZ (+/- 10%)
• Signal transmission interval: Intermittent 22 sec (+/- 4 sec)
• High voltage surfaces: 8 pcs
• High Voltage Voltage: 400 V DC (+/- 50 V)
• High voltage scattering time: max. 60 seconds (after power off)
• Unit: waterproof IP65
• LED: turns ON when the audio signal is transmitted
