Discontinued

Parking sensors FBSN-8RF

APRI | FBSN-8RF

Parking assistant APRI PM FBSN-8RF is top quality european product. The model contains 8 sensors determined for mounting into front and rear bumper, also wireless display and 3 different sensor adapters included.


Discontinued

Parking assistant APRI PM FBSN-8RF is top quality european product. The model contains 8 sensors determined for mounting into front and rear bumper, also wireless display and 3 different sensor adapters included.

Set not includes drill - drill holes are depending by type of bracket - O18/22/24mm.

Function:

  • Automatic deactivation of the front sensors, if the speed exceeds approximately 10km/h (speed signal must be connected)
  • Temporary deactivation of front sensors by timer
  • Temporary deactivation of rear sensors (by switch or by towing bar socket)
  • MUTE function - car audio is automatically faded-out during indication of obstacles
  • Time window - front sensor are active after the ignition switching ON
  • Fault sensor is automatically detected
  • Settable volume of the speaker (located inside display unit)

Technical parameters:

  • Supply voltage: 9-30V DC
  • Current consumption: 350 mA max.
  • Operational temperature: -25 / + 70°C
  • Working frequency: 40kHz
  • Detection range of front sensors: max. 95 cm (default on 80cm)
  • Detection range of rear central sensors: max. 180cm (default on 160cm)

Package:

  • 4 front sensors (marked with brown colour)
  • 4 rear sensors (two central are marked with black colour, two corner are marked with blue colour)
  • main control unit
  • rear control unit
  • front cable harness + Rear cable harness
  • rear cable harness with link cable
  • display
  • sensors holders

Parameters

Power Suply 12VDC
Number of sensors 8 sensors
Display Wireless display, LCD display
Manufacturer Apri
Weight 0.931 kg
